LG U+ Provides variety of service plans create new lifestyle for customers

Leading New Datacenter ParadigmLG U+ Gasan Center

  • Space

    • Gross Floor Area : 75,000㎡
    • Computer Room : 10,065㎡
    • Floor Height : 5.1m
    • Access floor : 60cm
  • Infra

    • Tier Level : Similar to Tier Ⅲ Level
    • Power : 40,000kw
    • UPS Power : Average 3.3 ~ 4.4 kW/Rack
    • Rack Cooling Available Capacity : Average 4.5kW/Rack

Key benefits

Scalability

  • Minimizing cost & time for additional system via modular system
  • Cooling duct system, panel board, cable tray, etc.

High Availability

  • Dualization of power system
  • 2N or N+1 system of power/constant temperature and humidity
  • N+2 distributed UPS and dualization of storage battery system
  • Duplicated UPS power via STS

Excellent Security

  • Thoroughly phased Security System
  • 01.Security Outside the Building
    • Zoom & Tilt CCTV
  • 02.Security Inside the Building
    • Speed gate in front of the elevator on the first floor
    • RF-card in the elevator
    • Bio-scanning and RF-card at the entrance of computer rooms
  • 03.Security within Computer Room
    • Bio-scanning security system, RF-card/security key in front of cage
    • CCTV between racks

Total Support Service

  • 24/7 operation of a control room and status monitor
  • Integrated management/control of every IDC system such as network, power, constant temperature and humidity, fire-fighting, security system, etc.
  • Error prevention system of SOP in an emergency
  • Customer support with opening, working, technical supports, etc.

Customer Amenities

  • Various customer amenities are provided in the intelligent building
